FIRST CNC Vertical Machining Center Model MCV-2000 Year 2006 Control Fanuc 18i-MB Technical Specifications (Subject to verification) Travels X-Axis 2050 mm (80") Y-Axis 1150 mm (45") Z-Axis 760 mm (30") Spindle Spindle Type BT-40 Max. spindle speed 120-15,000 rpm Spindle motor 20HP (Continuous Rating) ATC 24 Table Table size 2200 mm x 1000 mm (86”-39.3") Max. table loading capacity 3000 kgs (6600 Lbs) Dimensions Floor area 7,000 x 4,000 mm (23’ x 13’) Weight 14,000 Kg (31,000 lbs.) Equipped with • CNC FANUC Series 18i-MB • Lift up chip conveyor • MPG hand wheel • Spindle Chiller • Schneeberger linear roller guideways
